第20卷第3期 2012年3月
文章编号
1004-924X(2012)03-0520-07
光学精密工程
Optics and Precision Engineering
气溶胶对天空偏振辐射影响的测量
褚金奎*，王威，崔岩，支炜，高启升
（大连理工大学精密与特种加工教育部重点实验室，辽宁大连116024）
Vol., 20No.3
Mar.2012
摘要：研究了气溶胶光学特性对天空偏振辐射的影响以获得实际的天空偏振分布模式。采用自主搭建的天空偏振辐射测量系统，于不同日期、同一地点在太阳子午面内进行了若干实验，分别测量了太阳高度角约为60°时，435～465nm，535 ～565nm，685~715nm3个波段光在散射角为90°时对应的偏振度和辐射强度。用大气压强、能见度等参数进行理论计算获得了气溶胶光学厚度。当气溶胶光学厚度在0.2～0.55间逐渐增大时，3个波段对应的最大偏振度分别从43% 减小到22%、从41%减小到21%、从38%减小到19%，面对应的辐射量不断增大。实验结果表明；随着气溶胶光学厚度
的增大，偏振度不断减小，尤其是对长波长，偏振度的衰减更明显，从而不利于偏振光导航。关键调：大气光学；大气散射；天空偏振辐射；气溶胶；气溶胶光学厚度
中图分类号：0436.3;P407.4
文献标识码：A
doi:10.3788/OPE.20122003.0520
Measurementforinfluenceof aerosols onpolarized skyradiance
CHU Jin-kui', WANG Wei, CUI Yan, ZHI Wei, GAO Qi-sheng
(Key Laboratory for Precision and Non-traditional Machining Technology of the MinistryofEducation,DalianUniversityofTechnology,Dalianll6024,China)
Correspondingauthor,E-mail:chujk@dlut.edu.cn
Abstract: The influence of the optical properties of aerosols on polarized sky radiance was researched to obtain the actual polarized sky radiance distribution model. Using the polarized sky radiance meas-uring system set up by ourselves, a lot of experiments were done at the same place but different dates. The degree of polarization and polarized sky radiation were acquired through these measurements in the solar altitude angle about 60°and the scattering of 90°for three wave bands of 435—465 nm,535-565 nm and 685-715 nm. The aerosol optical depth was calculated by theory formula according to at-mospheric pressure and visibility. When the aerosol optical depth increases from 0. 2 to 0. 55, the de-grees of polarization for the three different wave bands decrease separately from 43% to 22%, 41% to 21% and 38% to 19%, but the radiation shows a trend of increase. Experimental results indicate that as the increase of aerosol optical depth, the degree of polarization will decrease, especially more signif-icantly reduction for the longer wavelength. Therefore, the increase of aerosol optical depth is not conducive for the navigation according to polarized light
收稿日期：2011-10-31；修订日期：2011-12-30
基金项目：国家973重点基础研究发展计划资助项目（No.2011CB302101，No.2011CB302105)；中央高校基本科研
业务费专项资金资助项目（No.DUT10ZD104）
