模具技术2017.No.6
文章编号：1001-4934(2017)06-0055-06
板材弯卷成形技术的研究进展
何雪婷，王玉华，朱富慧，李细锋（1.上海飞机制造有限公司，上海201324；
2.上海交通大学塑性成形技术与装备研究院，上海200030）
55
摘要：板材弯卷成形技术是制造筒形件、锥简形件、弯曲件乃至变曲率件的有效手段。介绍了对称式三辊弯卷成形、非对称式三辊弯卷成形和四辊弯卷成形三种广泛应用的板材弯卷成形技术，分析了三者的基本原理、特点和区别，概述了板材弯卷成形理论分析和有限元仿真的研究进展。随着弯卷成形技术的复杂化，需要发展新的弯卷成形理论分析模型来适应特定的弯卷成形工艺，必要时需要引入数值仿真研究弯卷成形过程。
关键词：弯卷成形；理论分析；有限元仿真
中图分类号：TG306
文献标识码：A
Research progress of plate roll-bending processes HE Xue-ting, WANG Yu-hua, ZHU Fu-hui, Li Xi-feng
Abstract: Roll-bending (RB) of plates is an effectivc process for fabricating cylindrical scg ments,conical componcnts,and curved parts with uniform or variable curvature.Three widely uscd roll-bending rcgimes including pyramidal three-roll, asymmetrical three-roll and four-roll types are introduced. The fundamental principles, characteristics and differences among thesc three techniques are analyzed. The rescarch progress in theoretical analysis and finite element simulation of RB process are also revicwed.For the more complex roll-ben-ding process, it is nccessary to develop new roll-bending analysis models to adapt to the spe-cific process and to apply the numerical simulation method to investigate the roll-bending process.
Keywords: roll-bending process; theoretical analysis; finite elemcnt simulation
材在摩擦力作用下进人成形区，经历塑性变形
0引言
板材弯卷成形是一种通过辑轮将板材弯曲成一定曲率或变曲率工件的连续成形技术，板收稿日期：2017-06-30
后获得特定的曲率。与其他冷成形技术相比，弯卷成形具有成形半径灵活、材料适应性广、设备吨位小、表面质量好等诸多优点。因而，这种板料成形方式广泛应用于管材和弯曲件的制
基金项目：上海市引进技术的吸收与创新年度计划(15XI-1-15)。
作者简介：何雪婷（1986—），女，工程师。万方数据
