基于FASTAMP的汽车横梁支架
拉延工艺设计及制件检测
朱红萍，解萌
（沙洲职业工学院机械动力工程系，江苏张家港215600）
39
摘要：针对某型号汽车横梁支架拉延成形过程，借助于FASTAMP软件对其成形过程、成形极限图和减薄率进行预测。设计了合理的拉延工艺，防止起皱和拉延不足等现象的产生。同时，利用UG软件进行了拉延模具整体结构方案设计，并对设计出的拉延模进行装配及产品试制；借助于三维自扫描仪，扫描获取试模后的制件云数据。利用Geomagic_ControlX检测软件进行检测，得出了符合要求的贴合度数值，验证了拉延模设计的合理性。
关键词：拉延成形；横梁支架；制件；检测
中图分类号：TG386
文献标识码：B
Drawing process design and parts detection of automobile crossbeam support
based onFASTAMP ZHU Hong-ping, XIE Meng
Abstract: For the stamping proccss design of a certain type of car beam bracket, the forming limit diagram and thinning ratio in thc forming process were predicted with the help of FAS-TAMP. The phcnomcnon of wrinkling and drawing can be prevented by rcasonable drawing process design. At thc samc time, thc overall structural scheme of drawing die was designed with UG softwarc. And thc designcd stamping dic was checked with assembling and produc-tion trial. The cloud data of thc stamped part was obtained by using 3D scanner. The value conforming to thc conncction was obtaincd by using the Gecomagic_Control X software which verify the rationality of stamping dic design.
Keywords:drawingforming;crossbeam support;parts;testing
制造周期"。本文针对某型号汽车横梁支架，对
0引言
随着CAD/CAE/CAM技术在模具设计、制造中的广泛应用大大缩短了产品的模具设计与
其进行了冲压工艺性分析，确定最合理的冲压分析方案，然后借助FASTAMP-NX4.0软件对拉延成形工艺进行仿真模拟，以确定合理的拉延工艺，最后利用UG软件设计出正确的拉延模具的
收稿日期：2017-06-27
基金项目：江苏省高校品牌专业建设工程一期项目，机械制造与自动化品牌专业项目（PPZY2015B184)。
作者简介：朱红萍（1978一），女，副教授。万方数据
