第42卷第9期 Vol.42
No.9 + 模具
饭
压技
FORGING & STAMPING TECHNOLOGY
软硬模辊式冲压模具设计及工艺优化
刘勇
(宜宾职业技术学院现代制造工程系，四川宜宾644003）
2017年9月 Sep.2017
摘要：软硬模辑式冲压模具解决了传统钢质模辑冲装置存在的干涉问题，但在实际使用中仍存在诸多缺陷，如：上下辑的易设计。优化调鉴了下辑高度的模形机构，保证冲压时的重叠量且更容易实现上下辑的水平度；将辑式冲压机上的平刃口因柱冲头改为中空内斜刃冲头，减小了冲压后产生的塌陷深度，提高了板料的平整度。经计算仿真和实验验证，表明本文所提出的优化方案切实可行，能够有效提高冲压质量。
关键词：辑式冲压模具；模形结构；模具缺陷；冲头；冲裁力 DOI: 10. 13330/j. issn. 1000-3940. 2017. 09, 020
中图分类号：TG76
文献标识码：A
文章编号：1000-3940（2017）09-0107-05
Design and process optimization on soft and hard die roller stamping die
Liu Yong
( Department of Moderm Manufacturing, Yibin Vocational and Technical College, Yibin 644003 , China)
Abstract : The interference problem of traditional steel die roller stamping device has been solved by the soft and hard die roller stamping die, but there are still many defects in practice, such as the difficulty in adjusting upper and lower rollers and the large deformation in blan-king of the sheet metal. Therefore, combined with the actual application of stamping die, the structure of the soft and hard die moller stam-ping die was improved, and the design of punch was optimized. Then, the wedge mechanism of lower roller height was optimized and adjus-ted to ensure the amount of overlap and achieve the levelness of the upper and lower mllers easily. Furthermore, the eylindrical punch of the flat edge in the roller press was changed into a hollow inner inclined blade punch to reduce the collapse depth after stamping and improve the flatness of sheet metal. The simulation and experimental results show that the proposed optimization scheme is feasible and can effectively improve the quality of stamping.
Key words : roller stamping die; wedge mechanism; die defect; punch; blanking force
随着工业产品质量的不断提高，冲压产品呈现
收稿日期：20170323；修订日期：20170620 基金项目：四川省教育厅科研课题（17ZB0501）
作者简介：刘
勇（1986-），男，碳士，讲师
E-mail: yoeg_ eagle@ sina com 参考文献：
[][2] 3
中国机械工程学会塑性工程学会，般压手册：第一差【M] 北京：机械工业出版社，2007
Plastic Engineering Society of China Mechanical Engineering Socie-ty. Handbook of Foeging: Vol. 1 [ M]. Beijing: China Machine Press，2007.
石小荣。多工位齿轮热模锻自动化锻造线[]]，金属加工， 2013, (19) : 11 12.
Shi X R. Automatie forging line for multi station gear hot forging[J]. Metal Working, 2013, (19) : 11 12.
杨成患，王洪兴。如何实现2.0L曲轴在4000t步进案自动
万方数据线上量产[1]。锻造与冲压，2017，（5】：26-28，
出多品种、少批量、复杂化、精密化、更新换代快的特点，传统的冲压工艺越来越难满足需求[1-3] 我国板材冲孔工业规模虽大，技术却较落后，辑冲工艺的出现在很大程度上使当前冲压技术得到了定改善(+-6)
Yang C Z, Wang H X. How to realize the 2. 0 L erankshaft pro-duction on the 4000 t step beam automatie line [J]- Forging & Metalforming, 2017, (5) : 26 28.
[4][5]
蒋腾，孙勇．锻造自动化技术应用进展及改造建议【J]，金属加工,2014,(21):57.
Jiang P, Sun Y. Application progress and modification saggestion of autemation forging technology [J]. Metal Working, 2014,(21) : 5 7.
朱德嵩，张进，秦安刚。步进案式毁造自动化生产线工艺问题与对策[].锻造与冲压，2011，(10)：4950
Zha D S, Zhang J, Qin A G. Process problems and countemeas ures of autoematic production line of walking beam foeging [ J]-Forging & Metalforming, 2011, (10) : 49 50.
