第46卷第4期
石油与天然气化工
CHEMICAL ENGINEERING OF OIL & GAS
催化汽油加氢脱硫装置国V升级改造设计
接瑜
中国石油工程建设公司华东设计分公司
摘要某炼厂已投产的90X10°t/a催化汽油加氢脱硫装置原设计为满足国IV汽油标准的要求而建。同时，为了应对汽油升级步伐的加快，使其将来可以平稳过渡至国V汽油生产，设计中兼顾了国 V汽油的生产工况。其主体设备如反应器、加热炉采用“一步到位”的设计方法，而循环氢压缩机和新氢压缩机则根据机型的大小分别采取了“预留位置”和“一步到位”的设计方法。由此，不仅可满足目前的生产要求，也为将来国V汽油的顺利升级奠定了基础。但由于加工原油的品种发生了变化，在进行国V 汽油升级改造时，催化汽油的硫质量分数由150X10-°升高至200X10-°，分馅塔的切割比例与原设计国V工况相比由4：6变成了3.5：6.5。结合新国V工况下操作条件的变化及实际装置运行过程中遇到的问题，对该装置进行了增加1台加氢后处理反应器、增加1台循环氢压缩机、更换加热炉燃烧器、更换循环氢脱硫塔塔盘以及冷换设备等措施，顺利完成本次改造。
关键词催化裂化汽油加氢脱硫国V汽油标准改造
中图分类号：TE624.4+31
文献标志码：B
DOI:10.3969/j.issn.1007-3426.2017.04.003
RevampdesignoftheFCCgasolinehydrodesulfurization
unit to upgrade to national V gasoline
JieYu
CN PC EastChina Design Institute Co ., Ltd., Qingdao, Shandong+ China
Abstract: An FCC gasoline hydrodesulfurization unit of o.9 Mt/a in a refinery was designed to meet the national IV gasoline standard. In order to reach the national V gasoline standard in the future , the main equipments such as reactor and furnaces were designed to satisfy the the national IN gasoline standard. The recycle hydrogen compressor was designed to satisfy the national IV gasoline standard and the place was reserved taking the national V case into consideration while the hydrogen make-up compressor was designed to satisfy the national V gasoline standard just by one-step. The orginal design was not only to meet the national standard of gasoline IV but also laid a foundation to the smooth transition to the national standard of gasoline V . Due to the change of crude oil variety , the sulfur mass fraction of FCC was increased from 150 X 10- to 200 X 10when upgraded to the national V gasoline. The cut proportion of the fraction column was changed from 4 : 6 to 3.5 : 6.5 . Based on the change of operating conditions and problems encountered in the actual operation process , the revamp of the unit was conducted by adding a new post-hydrotreating reactor and recycle hydrogen compressor,replacing the burners of heating furnace, the tower tray of recycle hydrogen desulfurization tower and the heat exchangers .
Key words: FCC gasoline, hydrodesulfurization , the national V gasoline standard, revamp
11
作者简介接瑜（1983一），女，高级工程师，2006年毕业于天津大学化学工艺专业，研究生学历（工学硕士），现就职于中国石油华东设计院有展墙，从事石油炼制工作，已发表论文近10篇，多次获省部级奖励。E-mail:jieycnpccei.cn
