第32卷第1期 2011年2月
内燃机工程
Chinese Internal Combustion Engine Engineering
文章编号：10000925(2011)01—0049—05
Vol.32 No.1 February.2011
320010
汽油机新型润滑系统一维仿真及试验研究
丁宁1，”，高卫民，平银生”，陈明”，崔权”，于波”
（1.同济大学，上海201804;2.上海汽车集团股份有限公司技术中心，上海201804）
1-DSimulationandExperimentStudyonaNewTypeof
LubricationSystemforGasolineEngine
DING Ning'-?,GAOWei-min’,PING Yin-sheng,CHENMing’,CUI Quan?,YUBo?(1.Tongji University,Shanghai 201804,China;2.Saic Motor Technical Center,Shanghai 201804,China)
Abstract: Simulation and experiment study on the main oil gallery pressure feedback control lubrica tion system of gasoline engine were conducted. In the steady state simulation, a series of parameters e, g. oil o(extreme condition) were compared and analyzed, And the transient state simulation was performed in conditions while the engine under normal state was accelerating from 3 500 r/min to 4 500 r/min, Finally, the simulation results were verified by oil pump test and engine bench test. The test results show that the oil pressure, flow and velocity of engine lubrication system are all in the appropriate ranges, In the transient process of the lubrication system, conver-gence of the oil pressure wave, as well as oil pressure stability are good. In addition, the lubrication system has an i-deal matching and adaptive abilities in the temperature range from 90 C to 140 'C.
摘要：介绍了主油道油压反馈控制的汽油机新型润滑系统。在稳态仿真计算中，对比分析了正常工况(90℃)和极限工况（(140C)下各管路润滑油的压力、流量和流动速度。以正常工况下发动机3500r/min升至4500r/min的加速过程为例，进行了瞬态特性的仿真。并用机油泵的性能试验和发动机台架试验进行验证。试验结果表明；发动机油压、流量、流速均在合理的范图内；润滑系统在瞬态过程中压力波动收效性好，油压稳定性较高；机油温度在90～ 140℃时，系统有理想的匹配适应性。
关键词：内燃机反馈控制；稳态；瞬态；加速过程；机油泵
Key words: IC engine; feedback control; steady state; transient state;
acceleratingprocess;oilpump
中图分类号：TK411.9
0概述
文献标识码：A
计理念和方法在国外广泛采用，取得了很好的效果。本文在排量为2.0L的直列4缸车用汽油机润滑系
近年来，随着CAE技术的迅速发展，发动机润滑系统的设计方法发生了巨大的变化，改变了过去从总成开发过渡到系统试验开发的过程。借助于先进的一维设计分析软件Flowmaster直接进行系统设计，再指导总成性能开发，自上而下，大大提高了发动机润滑系统开发的水平和效率)。这种新的设
收稿日期：2009-07-23
统设计开发过程中采用了国内先进的主油道油压反馈控制策略，并应用了商业分析软件Flowmaster7，进行了该润清系统的一维稳态与瞬态过程的分析和
计算，最后进行了试验验证。新型润滑系统结构组成
作者简介：丁宁（1981一），男，博士生，主要研究方向为内燃机CAE技术，E-mail;dingning5551430@163，com。万方数据
