永磁同步电机调速系统的自抗扰控制
周涛
（洛阳师范学院物理与电子信息学院，河南洛阳471022)
Mar.24No.3
Mar.2016
摘要：提出了一种利用反双曲正弦函数的一阶自抗扰控制器，以提高永磁同步电机正弦波脉宽调制（SPWM）调速系统的跟踪精度。研究了永磁同步电机转速环的数学模型；分别设计了一阶跟踪微分器和二阶扩张状态观测器，利用李雅普诺夫函数分析了它们的收敛性；构造了转速环的一阶自抗扰控制器，同时证明了一阶自抗扰控制误差系统的渐近稳定性。最后，将该新型一阶自抗扰控制器作为永磁同步电机的转速调节器，分析了自抗扰控制永磁同步电机的 SPWM调速系统。仿真实验表明：自抗扰控制调速系统速度阶跃跟踪的调整时闻约为0.15s，稳态误差小于0.28r/min；同一调速系统正弦响应的最大跟踪误差约为17r/min。与PI控制调速系统相比，自抗扰控制永磁同步电机调速系统阶跃
响应快速而平稳，无超调，稳态误差小；另外，系统正弦响应的跟踪性能好，跟踪误差小。关键词：永磁同步电机；一阶自抗扰控制器；反双曲正弦函数；调速系统；渐近稳定
中图分类号：TM351;TP273
文献标识码：A
doi: 10.3788/OPE.20162403.0582
Activedisturbancerejectioncontrolof speedgoverning systemfor
PMSM ZHOUTao
(College of Physics and Electronics Information, Luoyang Normal University, Luoyang 471022, China)
*Correspondingauthor,E-mail:zhoutao041@163.com
Abstract: A first-order Active Disturbance Rejection Controller(ADRC) with an arc-hyperbolic sine function was presented to increase the tracking precision of the Sinusoidal Pulse Width Modulation(SPWM) speed governing system of a Permanent Magnet Synchronous Motor(PMSM). A mathematical model for the velocity loop of the PMSM was studied. Then a first-order tracking differentiator and a second-order extended state observer were designed respectively and their convergences were analyzed by using the Lyapunov function. The first-order ADRC of the velocity loop was constructed, and the asymptotic stability of the first-order ADRC error system was verified. Finally, the designed first-order ADRC was used as the rotating speed adjuster of the SPWM, and the SPWM speed goverming system with the ADRC was analyzed.Simulation experiments demonstrate that the speed step response adjustment time of the SPWM speed governing system with the ADRC is 0.15s, the steady error is less than 0.28 r/min, and the maximum sine tracking error is 17 r/min. As compared with a PI controller, the governing system with the ADRC is characterized by fast and stable step response, smaller stable error and no overshoot. Moreover, it shows better sine tracking performance and smaller tracking errors.
Key words: Permanent Magnet Synchronous Motor(PMSM); first-order Active Disturbance Rejection
Controller(ADRC); arc-hyperbolic sine function; speed governing system; asymptotic stability
收稿日期：2015-08-06；修订日期：2015-10-26
基金项目：国家自然科学基金资助项目(No.61273161)：河南省科技攻关计划资助项目(No.142102210474)：河南省教
育厅科学技术研究重点项目(No.14A413007)
