周靖：缓蚀剂批处理对高酸性气田集输工艺的特殊要求
缓蚀剂批处理对高酸性气田集输工艺的特殊要求周靖1
摘要：以普光气田主体、大湾区块及元坝气图等高酸性气田集输工艺设计中遇到的缓蚀剂批处理带来的实际问题为例进行分析认为，缓蚀剂批处理对高酸性气国集输工艺流程及安装有特殊要求：对于输气量较大的集气干线尽量采用复线或同沟数设的管网布局；对于有复线经过的集气站场，出站管线应分别接入复线，并要精确计量进入每条管线的输气量；如果一条集气干线经过若干集气站场，建议沿线经过的集气站场都设置收发球装置
关键词：高酸性气田：缓蚀剂：批处理：集输工艺 Doi : 10.3969/j.issn.10066896.2016.8.018
Special Needs of Corrosion Inhibitor Batch Processing for Gathering Process in
High Sour Gas Field Zhou Jing
Abstract: This paper analyzes some special requirements for gathering process and installa tion process from some real problems of corrosion inhibitors batch processing during the con struction of the Puguang gas field, the Dawan gas field and the Yuanba gas field. When the ges gathering trunk line has larger transmission cepacity, the pipeline network layout would be better to employ double track pipelines or one ditch laying pipelines; when the gas gath ering stetion drilled through by doubletrack pipelines, all outgoing pipelines should be con nected to the doubletrack pipelines respectively, and each pipeline' s gas transmission flux should be measured accurately; when a single gas gathering trunk line drills through several gas gathering stetions, the stations along the route are recommended to set receiver and launcher. Key words: high sour gas field; corrosion inhibitor; batch processing; gathering process
为了有效地控制管线内腐蚀，高酸性气田集输
工程一般采取缓蚀剂预涂膜、连续加注及缓蚀剂批处理措施叫。为防止在后期设计或现场服务期间被迫变更设计，以普光气田主体、大湾区块及元坝气田等高酸性气田集输工艺设计中遇到的缓蚀剂批处理带来的问题为例进行分析总结，并提出合理化设计建议，为以后类似的设计提供借鉴
缓蚀剂批处理作业原理
高酸性气田缓蚀剂批处理技术是指在两只清管球之间加人适量缓蚀剂或柴油，以高压天然气作为动力源推动导向清管器和镀膜清管器进行工作，缓蚀剂通过特殊亲金属化学键作用与管内金属表面绩合形成一层保护膜，达到保护管道的目的。通过定
"中石化石油工程设计有限公司成都分公司 60
期对集输管道进行批处理作业，能及时修补管道上形成的极强黏性薄膜，清除管道内部杂质和各类流积物，有效防止集输天然气中HS、CO.及蚀性凝析水等造成的各种腐蚀
缓蚀剂批处理作业清管运动示意图如图1所示，运动方向由右向左。
批量缓蚀剂
导向清管器
镀膜清管器
图1缓蚀剂批处理作业清管运动示意图对集输工艺流程的一般要求
缓蚀剂批处理对集输工艺流程的一般要求主要
