第46卷第5期
分析计量与标准化
石油与天然气化工
CHEMICAL ENGINEERING OF OIL & GAS
ICP-AES内标法测定铬系乙烯聚合催化剂中 Cr、Ti、Mg、Al的含量
荣丽丽刘丽莹邓旭亮赵铁凯曹婷婷中国石油天然气股份有限公司石油化工研究院大庆化工研究中心
摘要采用微波消解技术对铬系乙烯聚合催化剂进行了处理，制备样品水相测定溶液，对各元素分析谱线选择进行确定，对样品测定中产生的基体效应进行讨论，建立可靠的微波消解-等离子发射光谱法测定铬系乙烯聚合催化剂中Cr、Ti、Mg、Al含量的方法。溶液中Cr含量偏高，对Ti、Mg、Al的测定有显著的影响，加入混合内标溶液可以消除基体对待测元素的干扰。实验结果表明，各元素校准曲线线性相关系数均不小于0.9998，检出限Cr为0.00105mg/L、Ti为0.00135mg/L、Mg为0.00066 mg/L、Al为0.00234mg/L。按照该实验方法测定铬系聚乙烯催化剂样品中Cr、Ti、Mg和A1的含量，其结果的回收率为97,5%104，0%，相对标准偏差（RSD.6）为0,51%4，45%
关键词电感耦合等离子体发射光谱法ICP-AES微波消解铬系乙烯聚合催化剂基体效应内标法
中图分类号：TQ322
文献标志码：A
D0I: 10.3969/j.issn.1007-3426.2017.05.017
Determinationoftitanium,chromium,magnesiumandaluminuminchromium-based
ethylene polymerization catalysts by ICP-AES with internal standard method
Rong Lili,Liu Liying,Deng Xuliang,Zhao Tiekai, Cao Tingting
Daging Petrochemical Research Center, PetroChina Petrochemical Research Institute , Daqing, Heilongjiang+ China Abstract: The chromium-based ethylene polymerization catalyst was treated by microwave digestion , and aqueous sample solution was prepared . The selection of the analytical spectral lines for the measured elements was determined . The matrix effect in sample determination was discussed The determination method of Cr , Ti, Mg and Al in chromium-based ethylene polymerization catalyst with microwave digestion technique and inductively coupled plasma atom emission spectrometry (ICP AES )was established reliably . The high content of Cr element in solution had a significant effect on the determination of Ti, Mg and Al. Adding the mixed internal standard solution, the matrix interference to the measured elements was eliminated . According to the results , the linear correlation coefficient of the calibration curve of each element was not less than O .999 8. The detection limits of Cr,Ti,Mg and Al were 0.001 05 mg/L,0.001 35mg/L,0.000 66 mg/Land 0.00234 mg/L, respectively. With this method, the recoveries were between 97.50% and 104.0% , and the relative standard deviations (RSD, n=6) were between O.51% and 4.45%.
Key words: inductively coupled plasma atom emission spectrometry , ICP-AES, microwave digestion , chromium-based ethylene polymerization catalyst , matrix effect , internal standard method
83
作者简介蒙融丽（1978一），女，毕业于石油大学（华东)环境工程专业，本科，工程师，现就职于中国石油天然气股份有限公司石油化工研究院捷化工研究中心，从事石油化工产品分析测试技术研究工作。E-mail：rl459@petrochina.com.en
