第39参第5期 2017年9月
石油钻采工艺
OIL DRILLING & PRODUCTION TECHNOLOGY
文章编号：10007393(2017）05658-04
DOI:10.13639/j.odpt.2017.05.022
Vol. 39 No. 5 Sep.2017
基于TRIZ创新理论的新型高压损防堵水嘴
田辉邹克武王文成刘春哲李大伟
承德石油高等专科学校
引用格式：田辉，邹克武，王文成，刘春替，李大伟.基于TRIZ创新理论的新型高压损防堵水嘴[].石油钻采工艺，2017， 39(5): 658-661.
摘要：为了在有限空间内深索具有大通流面积、高压损特性的注水嘴，使其在注水过程中保证配水精度的同时具有良好的防措能力，应用TRIZ创新理论对具有高压损、防增特性的分层注水水嘴进行了深入分新和优化设计。通过功能及冲突矩阵分析，利用结构嵌套法对水嘴结构进行优化，并设计出具有嵌套形式的新型绕流对冲水嘴。通过数值模拟方法对新型水嘴的压损特性进行分析，结果显示，新型水嘴可在保证截面面积较大（不小于传统①4.0mm直孔的通流面积)的情况下提供优于传统 02.0mm直孔水嘴的压损特性，从而可在保证配水准确性的同时提升防堵能力，提高水嘴的免维护周期。
关键词：分层注水；高压水嘴；TRIZ；数值模拟
中图分类号：TE357
文献标识码：A
Study on high pressure loss anti-blocking water nozzle based on TRIZ innovation theory
TIAN Hui,ZOU Kewu,WANG Wencheng,LIU Chunzhe,LI Dawei
Chengde Petrolerm College, Chengde 067000, Hebei, China
Citation: TIAN Hui, ZOU Kewu, WANG Wencheng, LIU Chunzhe, LI Dawei. Study on high pressure loss anti-blocking water nozzle based on TRIZ innovation theory [ J ] -. Oil Drilling & Production Technology, 2017, 39(5): 658-661.
Abstract: It is aimed at exploring the water injection nozzle which is characterized by large flow area and high pressure loss in limited space, so as to ensure water allocation accuracy and good anti-blocking capacity in the process of water flooding recovery. The TRIZ innovation theory was applied to perform thorough analysis and optimal design on separate layer water injection nozzle which has the performance of high pressure loss anti-blocking. Based on function and collision matrix analysis, the water nozzle was structurally optimized by means of the structure nesting method, and a novel bypass reverse water nozzle with the nesting form was designed. And its pressure loss characteristic was analyzed by using numerical simulation. It is indicated that this novel water nozzle is superior to the traditional O2.0 mm straight hole nozzle in term of pressure loss characteristic while its cross section area is remained larger (not smaller than the flow area of traditional O4.0 mm straight hole). And thus, the anti-blocking capacity of the water nozzle is improved and its maintenance free cycle is extended while the accuracy of water allocation is guaranteed.
Key words: separate layer water injection; high-pressure water nozzle: TRiZ: numerical simulation
分层注水是目前应用最为广泛的提高石油采收率的方法"。随着中老油田注采不平衡问题的积累
和非均质复杂断块油层的开发，尤其是低渗透/超低渗透油层的开发，对分层注水的精度和稳定性提出
基金项目：河北省白然科学基金项目“离心泵空化演变机理分析及其对水动力性能的影响研究"（编号：E2016411008)；河就省高等学第一作者：田辉（1982-),2014年毕业于西安交通大学能源与动力工程专业，茂工学博士学位，现以事流体机械内部复奈流动分析及优化
设计的工作。通试地址：(067000)河北省承德市大学图区。联系电话：0314-2377120。E-mail：tianhuicfd@gmail.com
通讯作者：李大伟（1984-),2012年毕业于东华大学机械制造及其白动化专业，获工学硕士学位，现从事石油机械结构设计和制造信息化
方面的研究工作。通试地址：(067000)河北省承德市大学图区。联系电话：0314-2377023。E-mail：cdpclidawei@163.com
