安全与环保
石油与天然气化工
CHEMICAL ENGINEERING OF OIL &. GAS
集输站场放空管道低温工况探讨
陈俊文1余洋1边云燕1祝疆杜荟敏2
2017
1.中国石油工程建设有限公司西南分公司2.中国石油西南油气田公司输气管理处
摘要油气集输站场放空系统是站内设施的重要安全保障。在事故情况下，站内高压气体必须快速泄放。放空管道材质主要参考放空过程中管道的温度进行确定。为保证选材合理性与经济性，有必要深入探讨放空工况下介质和管壁低温工况。基于超压放空和紧急放空过程，结合工程热力学基本规律，分析了放空过程管道温度的影响因素，借助商用软件OLGA探讨并模拟了某集气站放空管道的温度变化规律。结果表明，超压放空后管道温度与介质温度较为接近，但紧急放空后管道温度与介质温
度存在明显差异；紧急放空工况中，管道积存气体、管道热容等对管道低温具有一定抑制作用；动态模拟为放空管道合理选材与降低成本提供了技术支持。研究成果为集榆站场放空管道精细化设计提供了一定的参考与借整。
关键词集输站场中图分类号：TE88
压力泄放放空管道低温
文献标志码：A
DOI:10.3969/j.issn.1007-3426.2017.03.021
Discussion on the operation conditionat low temperatures of vent line ingathering station
Chen Junwen',YuYang',Bian Yunyan',Zhu Jiang',Du Huimin
1. China Petroleum Engineering & Construction Corporation, Southwest Com pany, Chengdu, Sichuan, China, 2, Gas Transmission Management Department, PetroChina Southuwest Oil and
Gasfield Com pany,Chengdu,Sichuan,China
Abstract: The pressure relief system is the key safety guarantee for oil-gas station. Under accident conditions, the high pressure medium must be quickly relieved. The material of vent line is mainly determined by the pipeline temperature during relief. It is necessary to discuss the low temperature condition of the vent medium and vent line, to ensure the rationality and economy of the material selection. In this paper, based on the over-pressure relief and emergency relief process, the influence on the vent line temperature during relief was analyzed in combination with the basic law of engineering thermodynamics, and the low temperature rule of vent line was discussed and simulated with OLGA software. The results showed that the vent line temperature would be close to the relief medium temperature during over-pressure relief, but there would be significant temperature difference under emergency relief. The storage gas and vent line thermal capacity may have an inhibitory effect on the low temperature under emergency relief, and the dynamic simulation can provide technical support on the rational material selection and cost reduction of vent line. The study result will provide reference for fine design of vent line in the gathering station.
Key words: gathering station, pressure relief,vent line, low temperature 基金项目：四川省科技厅资助项目“页岩气低成本地面集输工艺技术研究"(2016SZ0001)。
作者简介：陈俊文（1987一），男，工程师，硕士，2012年毕业于西南石油大学油气储运专业，现主要从事天然气储运研究与设计
工作，E-mail：chenjunw_sw@cnpc.com,cn 万方数据
