第33卷第3期 2013年9月
核科学与工程
Nuclear Science and Engineering
快堆粘钠设备清洗回路的调试
刘绩伟，王景春，李凌霄，李君瑜，谢淳，禹春利，李
（中国原子能科学研究院，北京102413）
服
Vol.33No.3
Sep.2013
摘要：为了研究快堆粘钠设备的清洗技术，建造了粘钠设备清洗回路。该回路基于水蒸气-氮气清洗方法，主要设备包括低溢液氮贮槽、电热蒸汽发生器、清洗端、废液收集罐、水蒸气冷凝器、水环真空泵、氢分析仪等。通过调试试验，发现了回路存在的间题和采取了相应的改进措施，使清洗回路的功能得到了完善，并确定了清洗回路的操作步骤，为后续的粘钠设备清洗技术的研究提供了保证，同时获得了很多
可直接用于中国实验快堆(CEFR)设备清洗系统的经验。关键词：粘钠设备；水蒸气-氮气清洗；回路调试
中图分类号：TL43
文章标志码：A
文章编号0258-0918(2013)13-0238-07
CommissioningoftheCleaningLoopofSodiumContaminated
EquipmentinSodium-cooledFastReactor
LIU Ji-wei,WANGJing-chun,LI Ling-xiao,LI Jun-yu,XIE Chun,YU Chun-li,LI Xu
(China Institute of Atomic Energy, Beijing 102413, China)
Abstract: The water vapor-nitrogen test loop was constructed to study the cleaning technology of sodium contaminated equipment in sodium-cooled fast reactor. The main components of the loop include a liquid nitrogen storage tank, an electric heating steam generator, a cleaning tank, an effluent storage tank, a condenser, a vacuum pump and a hydrogen meter. After a series of commissioning tests, some problems were found and the corresponding improvement measures were taken. The experiment procedure of the loop which was confirmed by the commissioning tests provided a guarantee for the following studies on the cleaning technology of sodium contaminated equipment.A number of experiences gained from the commissioning tests could be used in the equipment eleaning system of China Experimental Fast Reactor (CEFR).
Key words: sodium contaminated equipment; water vapor-nitrogen process; loop commissioning
快堆采用液态金属钠作为冷却剂，由于钠收稿日期：2013-07-04；修回日期：2013-08-11
具有与水强烈反应和空气易燃的化学特性，
作者简介：刘绩伟（1984一），女，河北人，助理工程师，硕士，现从事中国实验快堆销工艺技术的研究工作 238
