第34卷
第1期
2014年3月
核科学与工程
Nuclear Science and Engineering
中间热交换器建模仿真研究
张厚明1，段天英”，王刚2，刘勇？，能文彬3，刘兆阳2
Vol.34No.1
Mar.2014
（1.国家核安全局华北核与辐射安全监督站，北京100191；2.中国原子能科学研究院，北京102413；
3，国家核安全局核与辐射安全中心，北京100082)
摘要：对于快堆热工水力和仪控系统设计人员来讲，中间热交换器建模仿真十分重要。本文针对中间热交换器采用Matlab/Simulink软件，建立了一种伤真模型，包括两种稳态计算方法和瞬态计算模型。两种稳态模型分别为“等节距”、“等换热量”方法，两种稳态计算方法得出的结果差别很小，出口温度计算值与实际值差别最大为3K。在各节段上建立能量守恒微分方程组，从而建立了解态计算模型，并且，
在一回路流量衰减工况下对中间热交换器内部一、二回路蕴度变化进行了计算，计算结果较好。关键词：快堆；中间热交换器；伤真；模型；Matlab
中图分类号：TL425
文献标识码：A
文章编号：0258-0918(2013)04-0107-08
Study on Modeling and Simulation of Intermediate Heat Exchanger
ZHANG Hou-ming',DUAN Tian-ying",WANG Gang’,
LIUYong",XIONGWen-bin',LIU Zhao-yang
(1. North Regional Office, NNSA, Beijing 100191, China;2. China Institute of Atomic Energy, Beijing 102413, China
3. Nuclear and Radiation Sefety Center, NNSA, Beijing 100082, China)
Abstract: Modeling and simulation of intermediate heat exchangers (IHX) is very important for designers of the thermal-hydraulic and I&C system of liquid metal fast breeder reactor plant (LMFBR). In this paper, a model composed of steady state algorithm and transient state model is developed for IHXs' analysis using Matlab/ Simulink software. The steady state algorithm includes two approaches, i. e. equal segment length and equal heat transfer methods.The difference of temperature distribution calculated from both approaches is little in direction of IHXs' length. The maximum difference between actual outlet temperature and calculated one is about 3K. On every segment, ordinary form of energy conversation equations are established, and so transient state model is developed. Loss of primary flow transient is simulated to evaluate this model, and it operates well.
Key words: LMFBR;intermediate heat exchanger (IHX);simulation;model;Matlab 收稿日期：2012-12-29；修回日期：2013-07-21
作者简介：张厚明（1982—），男，山东腺州人，博士研究生，主要从事核电厂控制、仿真研究
107
