第19卷第1期 2011年1月
文章编号
1004-924X(2011)01-002906
光学精密工程
Optics and Precision Engineering
Vol, 19No.1
Jan.2011
深紫外光刻照明系统光束整形单元的设计
赵阳1.2，巩岩1
(1.中国科学院长春光学精密机械与物理研究所应用光学国家重点实验室，吉林长春130033；
2.中国科学院研究生院，北京100039)
摘要：为了使曝光波长为193nm的深紫外光刻系统能够制备噪光线宽为90nm及以下节点的集成电路芯片，设计了采用环形照明模式且部分相干因子。连续可调，能满足不同曝光线宽要求的光刻照明系统光束整形单元。首先，用几何光学定律和三角函数推导了轴维镜移动距离与光束放大倍率之间的函数关系；根据对变借凸轮的合理性和装调公差灵敏度的分析，确定了轴锥镜组参数的变化范围，完成了变倍镜组与轴锥镜组合的光束整形单元的设计。最后，在组合系统后面加入了可连续变倍的缩束系统，实现了。的连续可调。设计结果显示，在环形照明模式下，归一化的环宽和外环直径。r分别在[0.25，1]和[0.4,1]内连续可调，满足设计要求。
关键词：深紫外光划；环形熙明；轴维镜；部分相干因子；无焦变倍镜组
中图分类号：TN305.7;O435.1
文献标识码：A
doi;10.3788/OPE.20111901.0029
Designofbeamshapingunitfordeepultraviolet
lithographicilluminationsystem
ZHAO Yangl-2,GONG Yan
(l.StateKeyLaboratory ofAppliedOptics,ChangchunInstituteof Optics,FineMechanics and
Physics,ChineseAcademyofSciences,Changchun130033,China;
2.Graduate University of Chinese Academy of Sciences,Beijing 100039,China)
Abstract: To manufacture the integrated circuit chips at 90 nm or below their nodes by using a 193 nm exposed wavelength deep ultraviolet lithography, a beam shaping unit for the lithographic illumination system was designed to achieve the annular illumination and the continuous adjustment of a partial co herent factor α to meet the requirements of different exposed line widths. Firstly, the function rela-tionships between the moving distance of axicon and the light beam magnification were deduced by u sing the laws of geometric optics and trigonometric functions, and the ranges of parameters of axicon were determined after analyzing the feasibility of zoom cam and the tolerance sensitivities. Then, the axicon and zoom lens were combined to implement the beam shaping unit. Finally, a kind of reducing scale zoom lens was designed to add into the combined system to achieve the continuously adjustment of the o. The result shows that the normalized annular width o and the outer diameter of annulus Couter can be adjusted continuously in the range of [o.25, 1] and [o. 4, 1], respectively , which meets
收稿日期：2010-01-13；修订日期：2010-05-27，
基金项目：国家自然科学基金资助项目（No,40974110）
