压电式快速控制反射镜的迟滞特性及线性化
袁刚1,2*，张小波1，王代华1,2，陈敏
（1.重庆大学光电技术及系统教育部重点实验室，重庆400044； 2.重庆大学光电工程学院精密与智能实验室，重庆400044）
摘要：针对压电式快速控制反射镜（FastSteeringMirror，FSM)的退滞间题，分析了压电式FSM的工作原理和迟滞特性，建立了基于Bouc-Wen算子的压电式FSM的数学模型及其参数辨识方法。通过Bouc-Wen算子模拟压电式FSM输出镜面偏转角度中的迟滞分量，并根据在两个相位相同的输人驱动电压信号下压电式FSM的输出镜面偏转角度曲线辨识Bouc-Wen算子的全部参数。在此基础上，提出了压电式FSM的前馈线性化方法。为了验证提出的数学模型和线性化方法的原理，建立了压电式FSM及其线性化控制器的快速原型系统和Bouc-Wen算子参数辨识实验装置，实验结果表明：本文提出的参数辨识方法能够准确辨识压电式FSM的Bouc-Wen算子参数，提出的前馈线性化方法能够将压电式FSM的输出镜面偏转角度与输人控制电压的线性度提高到2.3%，滞误差减小到土0.5%，满足实际应用对精确控制压电式FSM的要求。
关键词：快速控制反射镜；压电陶瓷登堆执行器；领斜镜；退滞；线性化
中图分类号：TN384;TH703
文献标识码：A
doi,10.3788/OPE.20152306.1650
Hysteresisandlinearizationofpiezoelectricfaststeeringmirror
YUAN Gangl-2·, ZHANG Xiao-bo', WANG Dai-hua'-*, CHEN Ming
(l.Key Laboratory of Optoelectronic Technology and Systems oftheMinistryofEducation,Chongqing400044,China;
2.Precision&IntelligenceLaboratory,Collegeof OptoelectronicEngineering,
ChongqingUniversity，Chongqing400044，China) Correspondingauthor,E-mail:cquyuan@cqu,edu,cn
Abstract: For the hysteresis of a piezoelectric Fast Steering Mirror (FSM), the working principle and hysteresis properties of the piezoelectric FSM were analyzed. The Bouc-Wen hysteresis operator based mathematical model of the piezoelectric FSM and the corresponding parameter identification method were proposed. The hysteresis component of excursion angle of the piezoelectric FSM was estimated by the Bouc-Wen hysteresis operator, and parameters of Bouc-Wen hysteresis operator were identified according to the excursion angles of the piezoelectric FSM at two driven voltage waves with the same phase position. On this basis, a feedback forward linearization method for the piezoelectric FSM was proposed, In order to validate the proposed mathematical model and linearization method, the rapid prototyping system for the piezoelectric FSM and a linearization controller and an experimental set for the parameter identification of the Bouc-Wen hysteresis operator were established. The experimental
收稿日期：2015-01-23；修订日期：2015-02-23.
基金项目：中央高校基本科研业务费资助项目（No.CDJZR12120005）
