文章编号：1001-4934(2017)04-0028-04
Die and Mould Technology No. 4 2017
空心矩形管标记制造工艺与模具设计
吴玉川，康海军，刘海英，钱梁，羊彦伦（中车眉山车辆有限公司，四川眉山620010）
摘要：针对空心矩形管因自身强度不足，在标记压印过程中易变形、压印字迹不清工艺。提出采用斜模自锁模具结构，并进行了模具设计以及制造验证，实现了空心矩形管标记的制造，保证了标记压印成形并达到工艺要求，保证了产品生产顺利进行。关键词：空心矩形管；标记；压印；斜楔；自锁
中图分类号：TG386
文献标识码：B
Manufacturing process and tooling design forhollow rectanglar tube mark
WU Yu-chuan, KANG Hai-jun,LIU Hai-ying,QIAN Liang, YANG Yan-lun
Abstract: Aimed at the problem that the hollow rectangular tube is deformed due to the lack of its own strength, and the imprinting is not clear during the process of marking imprint ing. The thesis analyzes the forming process of mark-stamping of hollow rectangular tube according to the structure characteristics. It is proposed to adopt wedge self-locking mould structure. Also the design and manufacturing of mould is completed for verifying. Thus the manufacturing of mark-forming stamp on hollow rectangular tube is achieved,it ensures the mark-stamping process to the technological requirement and the production is carried out smoothly.
Keywords:hollow rectanglar tube; mark; stamping;wedge; self-locking
用压印工艺时，因自身强度不足，造成空心矩形
0引言
随着市场对产品制造过程可追溯潮要求的日益提高，需要在产品或部件上留下生产厂商、生产日期、序列号等可追溯的标记，一些关键零部件要求加工伴随产品全生命周期的永久性标记。现可追溯标记制造普遍采用刻印机刻印工艺，其深度通常小于0.3mm；当深度要求大于 0.3mm时，需要采用压印工艺。空心矩形管采
收稿日期：2016-11-28
作者简介：吴玉川（1971一），男，高级工程师。万方数据
管易变形、压印字迹不清晰，故本模具采用斜模自锁模具结构设计，并对模具设计以及压印制造进行了验证。
工艺分析 1
我公司研制的一种铁路货车，要求在 140mmX100mmX6mm的空心矩形管（见图 1)上压制永久性标记，标记由6位阿拉伯数字
