50
文章编号：1001-4934(2018)02-0050-05
Die and Mould Technology No .2 2018
基于UG和VERICUT的塑料模嵌件数控加工
徐家忠
（陕西国防工业职业技术学院数控工程学院陕西西安710300）
摘要：在塑料模中，嵌件的加工是常见的加工内容。为满足产品的成型要求和模具的结构要求·嵌件上经常会出现陡峭的曲面及一些深腔结构，采用传统手工编程很难实现零件的NC程序编写，这给零件的加工造成了一定难度。针对某塑料模嵌件的结构及加工难点，研究基于UG的嵌件类零件自动编程加工，并基于VERICUT仿真平台对零件进行仿真加工，查看加工中零件的过切、欠切情况，避免了实际加工中存在的碰撞、干涉等情况。
关键词：塑料模嵌件：UG：VERICUT：数控加工
中图分类号：TG659
文献标识码：B
NC processing of plasticmould insertbased onUG and VERICUT
xUJia-zhong
Abstract:Inplasticmould,theprocessing of inserts is common processing content.In order to meet the forming requirements of the product and the structure of the mould, Steep curved surfaces and some deep cavity structures often appear on the embedded parts , which make it difficult to writethe NC programs by the traditional manual programming,and caused a certain difficulty to parts processing . Aimed at the structure and processing diffi-culties from plastic mould insert,Theautomatic programming andprocessing of insert based onUGwasresearched,and thesimulatingmanufacturing of parts based onVERICUT was taken in this paper,check the over cut and lack cut in the processing, to avoid the collision and interference existing in the actual processing, provided some reference and feasibility for the NC machining and actual production of complex insert parts .
Keywords : plastic mould insert ; UG; VERICUT; numerical control machining
复杂型面越来越多，精度要求也不断提高，采用
0引言
随着工业技术的不断发展和进步，机械产品的结构和功能越来越复杂，进而造成零件的收稿目期：2017-08-14
传统的加工方式已很难满足复杂零件的加工要求。塑料模嵌件因其具有复杂的曲面、沟槽、深腔等结构，在对其进行生产加工时，往往存在 NC程序编写困难、加工精度无法保证等问题。
基金项目：陕西省教育科学“十三五”规划2016年度课题（SGH16V038）。作者简介方擦撼（1970一），男，副教授。
