第39卷(2017)第6期智能化与控制
柴油机 Diesel Engine
某船用柴油机调速特性瞬态仿真分析
景国辉，郑亮”，李先南”，沈刚”，谭晓星
Vol. 39(2017) No. 6
（1.海军驻七一一研究所军事代表室，上海201108；2.七一一研究所，上海201108）
摘要：某高速荣油机用作船用发电机组原动机时，对瞬态性能有较高的要求，而原荣油发电机组为3级调速精度，现须提高到2级调速精度。建立了该机一维瞬态仿真模型，并根据该机稳态试验数据及机组瞬态试验数据进行标定；基于原机调速精度指标与目标要求的差距，提出了该机调速精度优化方法。仿真计算验证了该优化方案切实有效，优化后该机调速精度满足2级调速精度要求。关键词：船用柴油机；发电机组；调速特性
中图分类号：TK424.3*1
文献标识码：A
文章编号：1001-4357(2017)06001604
Optimization of Speed GoverningPerformance of a Marine Diesel
byTransientSimulation
Jing Guohui',Zheng Liang",Li Xiannan”,Shen Gang",Tan Xiaoxing
(1. Naval Deputy Office of Shanghai Marine Diesel Engine Research Institute, Shanghai 201108 ;
2. Shanghai Marine Diesel Engine Research Institute, Shanghai 201108)
Abstract: To be used as marine generation sets, a certain marine diesel has high requirement regarding to the transient performance. However, the speed goverming accuracy of the original diesel gensets was degree 3, and needed to be improved to degree 2. The 1D transient simulation model was built and cali-brated by both steady and dynamic engine testing data. With regard to the gap between the speed gover-ning performance of the original gensets and targeted requirement, the optimization method of improving speed goveming accuracy was put forward. The method was verified to be feasible and practical through
simulation calculation, and could meet with degree 2 speed goveming accuracy Key words: marine diesel; genset; speed goveming performance
0
引言
某船用柴油机在匹配不同电机时须根据调速精
度要求调整机组的惯量情况及调速器的控制参数。本文采用瞬态仿真计算手段研究该船用柴油发电机组由3级调速精度提高到2级调速精度的优化方法，以缩短机组调速精度优化周期及降低试验成本。
柴油机技术参数
该船用柴油机为V型12缸机，分为A列和B 列，每列6缸。采用MPC增压方式，每列连接一台增压器，共两台增压器。该机主要技术参数如表
1所示。
某船用柴油机技术规格表1
缸数型式缸径/mm 冲程/mm 压缩比连杆长度/mm 单缸排量/L
额定转速/（r·min-）额定功率/kW 平均有效压力/MPa
收稿日期：2017-09-11
作者简介：景国辉（1971-），男，高级工程师，主要研究方向为船用荣油机性能。
12 直喷四冲程 170 195 13.5 350 4.43 1500 1 251 1.89
