第42卷第10期 Vol. 42No.10
锻压技术
FORGING & STAMPING TECHNOLOGY
汽车座位加固件大型复杂多工位连续模设计
刘庆东1，夏琴香2
2017年10月 L10130
（1.广州工程技术职业学院机电工程系，广东广州510075；2.华南理工大学机械与汽车工程学院，广东广州510640）摘要：汽车座位加固件的形状复杂、精度要求高，需要经过冲孔、切边、拉延、翻边、整形、侧面修边、切断等冲压工序才能完成。通过分析汽车座位加固件的冲压工艺性，确定了双排排样，中间载体，左、右汽车座位加固件在同一套模具冲制，每个工位同时冲压左、右各两件产品，共11个工位的连续冲压工艺方案；对模具侧面修边、送料机构和模具整体结构进行了详细分析，并根据设计方案制造出该产品的多工位连续模。模具经过试冲，结果表明，设计的工艺方案和模具结构合理，产品尺寸精度符合图纸要求，可满足大批量生产的要求。
关键词：汽车座位加固件；多工位连续模；冲压；排样；斜模修边；送料机构 DOI: 10. 13330/j. issn. 1000-3940. 2017. 10. 026
中图分类号：TG386
文献标识码：A
文章编号：1000-3940（2017）10-0149-06
Design on large complicated multi -position progressive die for
automotivereinforcement-seat
Liu Qingdong',Xia Qinxiang
(1. Department of Mechanical and Electrical Engineering, Guangzhou Institute of Technology , Guangzhou 510075, China; 2. School of Mechanical and Automotive Engineering, South China University of Technology , Guangzhou 510640, China)
Abstract: The automotive reinforcement-seat with complicated shape and high forming precision was formed by piercing, trimming, drawing, flanging, sizing, side trimming and cutting. Through analyzing the stamping process and scheme of the automotive reinforce-ment-seat, it was detemined that the left and right automotive reinforcement-seats were fomed in the same die with the double-row layout and intermediate carrier, and the progressive stamping process with eleven positions were put forward. Then, the side trimming, feeding mechanism and whole die structure were analyzed, and the multi-position progressive die was manufactured based on the above design scheme. After the die is tested, the results show that the layout scheme and the die structure are reasonable and feasible. Thus, the di-mensional precision of part meets the drawing requirement, which meets the requirement of mass production.
Key words: automotive reinforcement-seat; multi-position progressive die; stamping; layout; inclined wedge trimming; carrying mechanisms
随着我国成为世界第一汽车生产大国以及我国模具制造水平的提高，越来越多的汽车结构件采用连续收稿日期：2017-04-22；修订日期：2017-07-05
基金项目；广州市先进制造技术特色专业学院项目（穗教高教(2014）42号）
作者简介：刘庆东（1964－），男，土，高级工程师 E-mail: kd64@ botmail. com
5[6]
昌志，马秀花，周思柱。基于ANSYS的阶梯式斜端面组合凹模CAE分析［J]．锻压技术，2012，37（1）：114-116.
Lyu Z P, Ma X H, Zhou S Z. CAE analysis of staged oblique end combined cavity die based on ANSYS [J]- Forging & Stamping Technology, 2012, 37 (1) : 114 116.
朱里红，韦洁。提高厚钢板小孔冲裁质量的工艺参数优化[J].锻压技术，2015，40（8)：140143.
模制造。目前，世界上许多超大型汽车制造企业，其冲压件约有30%~40%是用多工位连续模制造的。随着计算机技术以及加工工艺的发展，可以设计、制造出形状更加复杂和精度更高的零件，促使汽车结构件连续模也向着大型化、复杂化的方向发展[1-3]
高强钢板越来越广泛地应用于汽车结构件中[4]。郭鸣骥等对某汽车车门玻璃导轨结构件设计出合理可行的13工位级进模(5)。陈志超等对某汽
Zhu L H, Wei J. Optimization on process parameters for improving the quality of small hole punching on thick steel plate [J]. Forg ing & Stamping Technology, 2015, 40 (8) : 140 143.
[7]
刘静，张明，陈浩。基于响应面法的台阶式凸模冲载工艺参数优化［J】-塑性工程学报，2016，23（3）：52-57
Liu J, Zhang M, Chen H. Parameters optimization of step-shaped-punch blanking based on response surface method [J]. Joumal of Plastieity Engineering, 2016, 23 (3) : 52 57.
