2017年第6期
主题：8D打印+
3DPrint
基于Delta并联机械结构的3D打印机研究
蔡团团易继军吴康雄
（长沙理工大学汽车与机械工程学院，湖南长沙410076）
摘要：基于Delta并联机械结构相比于笛卡尔坐标系机械结构的优势，并将其用于3D打印机的研发与设
计，提出了一种基于Delta机构、低成本、网络化3D打印机设计方案。相比使用更加广泛的笛卡尔坐标系3D打印机，Delta式3D打印机允许更大的打印体积和更快的打印速度。该打印机以 STM32单片机作为核心控制器，以步进电动机作为驱动元件，驱动同步带转动，利用滑块控制打印头按照预定的轨迹行进。为减轻打印头的重量，提高打印速度，采用远程送料机构，并通过步进电动机送料，进行数字温控，配合打印头完成打印作业。为加快3D打印机推广及使用，提出互联网 3D打印方案，通过配备WiFi模块实现数据的无线传输与远程控制，并增加了自动调平、断电续打、断丝检测等功能，极大地增强了3D打印机使用的便利性。实践表明该打印机具有运动平稳、高速、高精度、成本低、易于控制等优点。
关键词：3D打印机；Delta机构：低成本：远程控制
中图分类号：TP334.8
文献标识码：A
DOI10.19287/j.cnki.10052402.2017.06.003
3DprintersresearchbasedonDetalstructure
CAITuantuan,YI Jijun,WUKangxiong
(College of Automobile and Mechanical Engineering, Changsha University of Science and Technology,
Changsha410076，CHN）
Abstract: Based on the Delta parallel the advantages of mechanical structure than Descartes'mechanical structure,
and use it to 3D printer research and design, this paper puts forward a kind of Delta structure, low cost, network design of 3D printer. Compared to the more widespread use of 3D printers Cartesian coordinate system, the Delta type 3D printers allow greater volume and faster printing speed. The printer uses STM32 microcontroller as the core controller, with stepping motor as driving element, by stepping motor drives the synchronous belt, use the slider control the print head according to the predetermined path. To reduce the weight of the print head, improve the print speed, using the remote transmission mechanism, and through the stepper motor feeding, digital temperature control, to complete the print head print jobs. In order to speed up the promotion and use of 3D printers, the internet 3D printing solutions are put forward, equipped with WiFi module implements wireless data transmission and remote control, and increase the function of the automatic leveling, power outages to continue, broken wire detection, great-ly enhance the use of 3D printers and convenience. Practice shows that the printer has the advantages of the smooth movement, high speed, high precision, low cost, easy to control.
Keywords:3D printer; Delta structure; low cost; remote control
目前，3D打印技术发展迅速，信息化、便捷化、个
人化和创意化将成为未来3D打印技术发展方向的核心。对此，本文提出一种基于Delta并联机械结构的网络化3D打印机设计方案。该方案具有结构稳定、成本低、精度高、速度快、易于控制等特点。
制造技术点机序万方数据
1FDM基本原理
熔融沉积制造（fuseddepositionmanufacturing， FDM)成形技术是一种采用材料，如塑料或金属丝，利用电加热方式将材料熔化、挤压成丝，逐线、逐层沉积
