第11卷第1期 2016年2月
中国舰
船研究
Chinese Journal of Ship Research
网络出版地址: http://www.cnki.net/kcms/detail/42.1755.TJ.20160119.1455.004.html
Vol.11 No.1 Feb.2016
期刊网址：www.ship-research.com
引用格式：付立军，刘鲁锋，王刚，等.我国舰船中压直流综合电力系统研究进展[J].中国舰船研究，2016，11(1)：72-79
FU Lijun, LIU Lufeng. W ANG Gang,et al. The research progress of the medium voltage DC integrated power system in China[J]. Chinese Jourmal of Ship Researeh,2016, 11(1) : 7279.
我国舰船中压直流综合电力系统研究进展
付立军，刘鲁锋，王刚，马凡，叶志浩，纪锋，刘路辉海军工程大学船舶综合电力技术重点实验室，湖北武汉430033
摘要：舰船综合电力系统可实现全舰能量的综合利用，被誉为是舰船动力的第三次革命。介绍了一代和二代舰船综合电力系统的技术特征。结合我国综合电力系统设备的技术现状，介绍我国一代半舰船中压直流综合电力系统的研究进展，分析了系统层面存在的难点，主要包括：系统建模和电磁暂态仿真、气轮机发电机组和柴油发电机组并联、系统稳定性分析和分层保护等，并给出了解决的方法，指出中压直流综合电力系统需要在中
压直流断路器、系统储能、系统安全运行和多时间、多目标能量调控方面进一步开展研究。关键调：综合电力系统；中压直流；能量调控
中图分类号：U664.14
文献标志码：A
DOI: 10.3969/j.issn.16733185.2016.01.009
Theresearchprogress of themediumvoltageDCintegratedpowersystem inChina
FU Lijun, LIU Lafeng, WANG Gang, MA Fan, YE Zhihao, JI Feng, LIU Larhui Science and Technology on Ship Integrated Power System Technology Laboratory ,
Naval University of Engineering, Wuhan 430033, China
Abstract: With the constant development of moderm marine technologies, the vessel energy now can be distributed through an Integrated Power System, which is known as the third vessel power revolution. In this paper, the technical features of the first and second generation integrated power system are introduced Next, based on the present domestic technical status, the research progress of the quasi second generation medium voltage DC integrated power system in China is presented, with the corresponding difficulties and problems analyzed, including the system model, electricalmagnetic transient simulation, the connected op-erator between the gas turbine generator set and the diesel generator set, the system steady analysis, and system layered protection. Finally, the solutions are proposed, which indicates that the development are re-quired on the medium voltage DC breaker, system energy storage, system safe operation, multitime scale, and multi object system energy regulation.
Key words: integrated power system; medium voltage DC; energy regulation
引言 0
舰船综合电力系统将传统舰船中相互独立的动力和电力两大系统合二为一，以电能的形式统-为推进负载、脉冲负载、通信、导航和日用设备等供电，实现了全舰能源的综合利用。采用综合
收稿日期：20150619
电力系统，不仅可以为舰船负载提供电源平台，而且能简化舰船动力系统结构、提高舰船系统效率降低舰船噪声能级、减少舰船全寿命周期费用，符合舰船信息化和智能化的发展趋势，代表着舰船动力系统未来的发展方向-，被誉为舰船动力从人力、风力到蒸汽动力再到核动力之后的第三次
网络出版时间：2016-1-1914:55
基金项目：国家重点基础研究发展计划资助项目(2012CB215103)；国家级重大基础研究资助项目；国家自然科学基金资助
项目（51377167）
作者简介：付立军(通信作者)，男，1967年生，教授.博士生导师。研究方向：电力系统仿真建模、分析，系统设计、能量管理。
Email; lijunfu2006@sina.cn
