BS EN 10029:2010
BSl Standards Publication
Hot-rolled steel plates 3 mm thick or above Tolerances on dimensions and shape
NO COPYING WITHOUT BSI PERMISSION EXCEPT AS PERMITTED BY COPYRIGHT LAW
BSi
raising standards worldwide" BSEN10029:2010
BRITISH STANDARD
Nationalforeword This British Standard is the UK implementation of EN 10029:2010. It supersedes BS EN 10029:1991 which is withdrawn. The UK participation in its preparation was entrusted to Technical Committee ISE/103,StructuralSteelsOtherThanReinforcements A list of organizations represented on this committee can be obtained on request to its secretary. This publication does not purport to include all the necessary provisions of a contract. Users are responsible for its correct application. 'BSI 2010 ISBN9780580577451 ICS 77.140.50 Compliance with a British Standard cannot confer immunity from legal obligations. This British Standard was published under the authority of the StandardsPolicy and StrategyCommittee on31December2010. Amendments issued since publication Date
Text affected BSEN10029:2010
EN 10029
EUROPEANSTANDARD NORMEEUROPEENNE EUROPAISCHE NORM
November 2010
Supersedes EN 10029:1991
ICS 77.140.50
English Version
Hot-rolled steel plates 3 mmthickorabove-Tolerances on
dimensions and shape
Toles en acier laminees a chaud, d'epaisseur egale ou superieure a 3 mm - Tolerances sur les dimensions et la
Warmgewalztes Stahlblech von 3 mm Dicke an -
GrenzabmaBe und Formtoleranzen
forme
This European Standard was approved by CEN on 23 October 2010. CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this Europe an Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning s uch national standards may be obtained on application to the CEN Management Centre or to any CEN member This European Standard exists in three official versions (English, French, German). A version in any other language made by tra nslation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions. CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
cen
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITE EUROPEEN DE NORMALISATION EUROPAISCHES KOMITEE FUR NORMUNG
Management Centre: Avenue Marnix 17, B-1000 Brussels
2010CEN All rights of exploitation in any form and by any means reserved
Ref.No.EN 10029:2010: E
worldwide for CEN national Members. BSEN10029:2010 EN10029:2010(E)
Contents
Page
Foreword. 1
.3
Scope Normativereferences Termsand definitions
4
2 3 4 Informationtobesuppliedbythepurchaser.. 4.1 Mandatory information...... 4.2 Options..... 4.3 Designation... 5 Form of supply 6
5 5
Tolerancesondimensions.
6.1 Thickness 6.2 Width.... 6.3 Length.. 7
Tolerances on shape....
7.1 Edgecamberandout-ofsquareness.. 7.2 Flatness..... 8
..8
Measurement
8.1 General. 8.2 Thickness 8.3 Width 8.4 Length. 8.5 Edgecamber 8.6 Out-of squareness... 8.7 Flatness..... AnnexA(informative)Listofproduct standards where dimensional standard EN 10029 is
9
10 10
....1
applied.
.12
......E
.....
.....
2 BSEN10029:2010 EN10029:2010 (E)
Foreword
This document (EN 10029:2010) has been prepared by Technical Committee ECISS/TC 103"Structural steels other than reinforcements", the secretariat of which is held by DIN. This European Standard shall be given the status of a national standard, either by publication of an identical text or by endorsement, at the latest by May 2011, and conflicting national standards shall be withdrawn at the latest by May 2011. Attention is drawn to the possibility that some of the elements of this document may be the subject of patent rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such patent rights This document supersedes EN 10029:1991. According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,Finland, France,Germany,Greece,Hungary,Iceland,Ireland,Italy,Latvia. Lithuania, Luxembourg,Malta, Netherlands,Norway,Poland, Portugal, Romania, Slovakia,Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
3 BSEN10029:2010 EN10029:2010 (E)
1 Scope This European Standard specifies tolerances on dimensions and shape for hot-rolled non-alloy and alloy steel plates with the following characteristics: a)Nominal thickness:3mm ≤t≤400 mm; b)Nominal width: w≥ 600 mm. Tolerances for products of width w < 6oo mm cut or slit from plate should be agreed between manufacturer and purchaser at the time of enquiry and order. This European Standard applies,but is not limited,to steel grades defined in EN 10025-2 to EN10025-6:2004+A1:2009,EN10028-2toEN10028-6,EN10083-2andEN10083-3EN10084,EN10085 EN 10149-2 and EN 10149-3, EN 10207 and EN 10225 (see also Annex A).It does not apply to stainless steels. This European Standard does not include round plates, custom-made plates, chequer or bulb plate for flooring and wide flats.
2Normativereferences The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments)applies EN 10079, Definition of steel products EN10163-1,Delivery requirements forsurface condition of hot-rolled steelplates,wideflatsand sections Part 1:General requirements EN10163-2,Deliveryrequirementsforsurfaceconditionsofhot-rolledsteelplates,wideflatsandsections Part 2: Plate and wide flats
3Terms and definitions For the purposes of this document, the following term and definition apply 3.1 plate see EN10079
4 Informationto be supplied bythepurchaser
4.1Mandatory information The following information shall be supplied by the purchaser at the time of enquiry and order: a) quantity to be delivered; b) designation of the product form (plate) C) numberof this dimensional standard (EN 10029)
4 BSEN10029:2010 EN10029:2010(E)
d) nominal thickness in millimetres; e) nominal width in millimetres; f) nominal length in millimetres. Plates ordered according to this European standard shall be delivered as follows:
tolerance class A for thickness unless otherwise stated (see 6.1, Table 1); trimmed edges; normal edge camberand out-of-squareness (see 7.1); normal tolerances for flatness, class N (see 7.2, Table 4).
If no information concerning points a) to f) of 4.1 is given by the purchaser, the supplier shall refer back to the purchaser 4.2Options A number of options are specified in this European Standard and listed below. If the purchaser does not indicate his wish to implement any of these options, the supplier shall supply in accordance with the basic specification of this European Standard (see 4.1) a) if thickness tolerance class B, C or D is required, include B, C or D in the order designation (see Clause 5
and 6.1); b) if plate with untrimmed edges is required, include NK in the order designation (see 6.2.2); c) if plate with limited edge camber and out-of-squareness is required, include letter G in the order
designation and define the required maximum values for edge camber and out-of-squareness (see 7.1); d) if plate with special flatness tolerances is required, include the letter S in the order designation (see 7.2.1
and Table 5); e) if plates with a nominal length I > 20 o00 mm are required, the agreed tolerances on length are to be
reported (see 6.3, Table 3): for plates with untrimmed edges, the chosen and agreed measuring points for the measurement of the thickness are to be reported (see 8.2).
f)
4.3Designation EXAMPLE
20 plates of steel S235JR (1.0038), as specified in EN 10025-2 according to this European Standard with
nominal thickness of 25 mm, thickness tolerance class B, nominal width 2 000 mm, r nominal length 4 500 mm, with trimmed edges, with limited edge camber and out-of-squareness, with special tolerances for flatness:
20 plates EN 10029-B-G-S
25x2 000× 4500 Steel EN 10025-2-S235JR
5 BSEN10029:2010 EN10029:2010 (E)
5 Form of supply Plate according to this European standard can be supplied:
with thickness tolerances of class A, B, C or D (see 6.1); with trimmed or untrimmed edges (NK) (see 6.2.2); with normal or limited edge camber and out-of-squareness (G) (see 7.1); with normal (N) or special (S) flatness tolerances (see 7.2)
6 Tolerances on dimensions 6.1 Thickness 6.1.1 Tolerances on thickness are given in Table 1. Plates may be supplied with either:
class A: for minus thickness tolerances depending on the nominal thickness: class B: for a fixed minus tolerance of 0,3 mm; class C: for a fixed minus tolerance of o,o mm; class D: for symmetrical tolerances.
Table1Tolerances onthickness
Dimensions in mm
Tolerances on the nominal thickness (see 6.1.1)
Nominal thickness
Class B
Class C
Class A Lower Upper Lower Upper Lower Upper Lower Upper 0,3 +0,7 -0,3 +0,7 0 +1,0 -0,5 +0,5 -0,4 +0,8 0,3 +0,9 0 +1,2 0,6 +0,6
Class D
t 3≤t<5 5≤t<8
8 ≤t<15 -0,5 +0,9 0,3 +1,1 0 +1,4 -0,7 +0.7 15≤t<25 0,6 +1,0 0,3 +1,3 0 +1,6 0,8 +0,8 25 ≤t<40 0,7 +1,3 0,3 +1,7 0 +2,0 1,0 +1,0 40 ≤t<80 0,9 +1,7 0,3 +2,3 0 +2,6 1,3 +1,3 80 ≤t<150 1,1 +2,1 0,3 +2,9 0 +3,2 -1,6 +1,6 150 ≤1<250 -1,2 +2,4 -0,3 +3,3 0 +3,6 -1,8 +1,8 250 ≤I≤400 1,3 +3,5 -0,3 +4,5 0 +4,8 -2,4 +2,4 These thickness tolerances apply outside ground areas (see 6.1.2).
At the time of enquiry and order the purchaser shall indicate if class A, B, C or D tolerances is required (see 4.1 and 4.2).If no class is stated, class A applies.
6
