JB/T 5835—2005
电力半导体器件用门极组合件
Components of gate terminal for power semiconductor devices
2005-0319 发布
2005P9-01 实施
目 次
前言..............................................m
1范围............................................1
2规范性引用文件........................................1
3型号及外形......................................    1
3.1 型号......................................... 1
3.2外形...........................................1
4尺寸...........................................  2
5技术要求...........................................3
5.1 外观..........................................3
5.2材质...........................................3
5.3 引线..........................................3
5.4套管...........................................3
5.5 引线拉力..............................          3
5.6  触头........................................  3
5.7触头工作压力.......................................3
5.8工作温度.........................................3
6检验规则...........................................3
6.1 质量一致性检验.....................................3
6.2鉴定检验.........................................4
7包装、运输、贮存和标志....................................4
7.1 包装..........................................4
7.2 运输........................               ...4
7.3 贮存........................................  4
7.4标志...........................................4
附录A （规范性附录）抽样方案................................ 5
AJ AQL抽样方案......................................5
A.2追加抽样方案.......................................5
图1型号组成.........................................1
图2 A型组合件.......................................1
图3 B型组合件........................................2
图4 C型组合件....................................    2
表A.1 AQL抽样表.................................... 5
表A.2 追加抽样表......................................5
