第31卷
第4期
2011年
12月
核科学与工程
Chinese Journal of Nuclear Science and Engineering
Vol.31No.4
Dec.
整体针翅管混合管束滑油冷却器
传热特性对比实验研究牛广林1,2，阎昌琪，孙中宁1，石
五帅1，南金秋1
（1.哈尔滨工程大学核能科学与技术学院，黑龙江哈尔滨150001；
2.黑龙江科技学院，黑龙江哈尔滨150001)
2011
摘要：对整体针翅管混合管束滑油冷却器进行实验研究，在壳程流通横截面积相同条件下，分别在单流程和双流程滑油冷却器中进行实验，得出混合管束在两种流程下的换热和流动阻力特性。结果表明：单流程布置单位体积换热量能达到双流程的1.5倍；总传热系数达到1.3倍；壳侧压降不到三分之一。实验结论
可以为流程选择和管型布置提供参考。文章最后给出适合工程应用的换热准则关系式。关键调：冷油器；双流程；整体针翅管；混合管束
中图分类号：TK124
文章标志码：A
文章编号：0258-0918(2011)04-0317-04
Comparativeexperimentstudyonheattransfercharacteristicsof
Iubricating-oil cooler with mixing integral pin-fin bundles NIU Guang-lin",YAN Chang-qi',SUN Zhong-ning', SHI shuai', NAN Jin-qiu
(1. School of Nuclear Science and Technology, Harbin Engineering University, Harbin of Heilongjiang Prov. 150001,China;2. Heilongjiang University of Science and Technology, Harbin of Heilongjiang Prov. 150001,China)
Abstract: The lubricating-oil cooler with mixing integral pin-fin bundles were studied experimentally. The single-flow and double-flow cooling experiments have been done with the same flow area of the shell. The characteristics of heat transfer and flow resistance were analyzed. Comparing a single-flow with double-flow arrangement, heat transfer capacity unit volume is 1.5 times; heat transfer coefficient is 1.3 times; pressure at shell side drops by less than one third. Experimental results provide reference for process selection and arrangement of tube. At last, heat transfer equation
from experiment was suggested for engineering application in the paper. Key words;oil cooler;double-flow;integral pin-fin tube;tubes mixed bundle
收稿日期：2010-10-28；修回日期：2011-09-20
基金项目：黑龙江省教育厅基金资助项目（11541320）
作者简介：牛广林(1973一)，男，山东济宁人，博士研究生，从事热工水力、强化传热、反应堆安全与小型化研究方向
317
