第21卷第12期 2013年12月
1004-924X(2013)12-3141-11
文章编号
光学精密工程
Optics and Precision Engineering
微流控的系统级设计苑伟政1.2，焦文龙1.2，常洪龙1,2
（1.西北工业大学陕西省微/纳米系统重点实验室，陕西西安710072； 2.西北工业大学空天微/纳系统教育部重点实验室，陕西西安710072)
Vol.21No.12
Dee.2013
摘要：微流控设计技术对于提高微流控设计效率，降低研发成本具有重要意义。微流控设计技术中的系统级建模与仿真是实现微流控快速设计、优化、验证的重要方法。本文首先对微流控设计的原理和方法做了简要介绍。在此基础之上，重点论述了微流控系统级设计中的两种主要方法一节点分析法和等效电路法，对两种方法的建模与仿真理论进行了分析，并总结了两种方法近十年来在国内外的研究发展概况和最新进展。最后，分析总结了这两种方法的优缺点，并对微流控系统级设计技术进行了总结与展望，指出微流控系统级建模与仿真技术在解决大规模、复杂性、多功能微流控系统的设计方面有巨大的优势。
关键调：微流控技术；系统级设计；建模；仿真
中图分类号：TH702
文献标识码：A
doi;10.3788/OPE.20132112.3141
Systemlevel designof microfluidics
YUAN Wei-zhengl-2-,JIAO Wen-longl-2, CHANG Hong-long'-2
(l.ShaanriProvinceKeyLaboratoryofMicro/NanoElectroMechanical Systems
NorthwesternPolytechnicalUniversity，Xian710072，China;
2.KeyLaboratoryof Micro/NanoSystemsforAerospaceof theMinistryof Education
NorthwesternPolytechnical University，Xi'an710072,China) Correspondingauthor，E-mail:yuanwz@nwpu.edu.cn
Abstract: It is important to design microfluidic technologies for improving the efficiency of microfluid-ics and reducing the costs of research and development. However, system level design, modeling and simulation are significant methods for rapid design, optimization,and verification of the microfluidics This paper introduces the principles and methods of microfluidic design, firstly. Then, it focuses on two main system level design methods, nodal analysis method and equivalent circuit method. After a brief discussion of microfluidic design technology, it introduces the modeling and simulation processes of the two methods, and overviews their research status and development trends in the last ten years at home and abroad. Finally, it summarizes merits and demerits of the two methods and discusses their development prospects. It points out that the system level design and modeling will be great su-
periority for design a microfluidic system with large-scale, complexity and multi-function. Key words: microfluidics; system level design; modeling: simulation
收稿日期：2013-05-06；修订日期：2013-07-01.
基金项目：国家自然科学基金资助项目（No.60979087)
