第23卷第5期
2015年5月文章编号
号1004-924X(2015)05-1416-08
光学精密工程
Optics and Precision Engineering
Vol. 23No.5
May.2015
谐振充电技术在火花开关触发系统中的应用
张兴亮1,2，郭立红1*，孟范江1，方艳超"，张振东1，毛书1（1.中国科学院长春光学精密机械与物理研究所，吉林长春130033；
2.中国科学院大学，北京100039)
摘要：为提高触发高功率横向励大气压（TEA）CO，激光器中旋转火花开关的稳定性和可靠性，减小火花开关触发系统的体积和重量，提出了将高频谱振充电技术应用于触发系统的方法。研发了采用全桥逆变结构和审联谐振软开关电路、输出电压大于38kV、翁出功率为2kW的高频高压充电电源并将其作为旋转火花开关触发系统。该系统的全桥逆变电路由智能功率模块（IPM)构成，采用MSP430单片机控制IPM驱动信号的频率、脉宽以及个数，直流电压经全桥逆变电路及串联谐振电路在高压脉冲变压器原边获得脉冲信号。此脉冲信号经高压脉冲变压器的升压和变压器次级整流 00
率下能连续稳定触发旋转火花开关，提高了触发系统的可靠性和稳定性，其体积及重量为脉冲式触发系统的1/2。关键调：TEACO，激光器；旋转火花开关；触发系统；串联谐振；充电电源
中图分类号：TN248.2;TM564
文献标识码：A
doi:10.3788/OPE,20152305.1416
Applicationof seriesresonantchargingtechnologyto
triggersystemforrotatedsparkswitch
Zhang Xing-liang-?, Guo Li-hong', Meng Fan-jiang' , Fang Yan-chao', Zhang Zhen-dong', MAO Shu-qin
(1.ChangchunInstituteof Optics,FineMechanicsandPhysics, ChineseAcademyofSciences,Changchun130033,China;
2.University of Chinese Academy of Sciences,Beijing 100039,China)
*Correspondingauthor,E-mail:guolh@ciomp.ac.cn
Abstract: To improve the stability and reliability of the rotated spark switch system in a high power Transversely Excited Atmospheric(TEA) CO, laser and to reduce the volume and weight of a trigger system for the rotated spark switch, this paper induces the series resonant charging technology into the trigger system. A high-frequency high-voltage charging power supply consisting of a full bridge inverter circuit and a series resonant soft switch circuit is developed. The charging power supply is taken as a trigger system for the rotated spark switch and offers a output voltage greater than 38 kV and a output power of 2 kV. In this system, the full bridge inverter circuits consist of Intelligent Power Models(IPMs), and the MSP43o is used to control the frequency, pulse width and the number of pulses for IPM driving signals. After full-bridge inverter circuit and series-resonant circuit get the
收稿日期：2014-05-18；修订日期：2014-07-30
基金项目：激光与物质相互作用国家重点实验室研究基金资助项目（No.SKLLIM0902-01)；长春市地院合作创新集
群专项资助项目（No.11DJ02）
