第23卷第5期 2015年5月
文章编号1004-924X(2015)05-1358-07
光学精密工程
Optics and Precision Engineering
Vol.23No.5
May.2015
型直线超声电机梁式夹持的结构设计 V
简月，姚志远”，杨模尖，刘振
（南京航空航天大学机械结构力学及控制国家重点实验室，江苏南京210016）
摘要：探讨了直线超声电机夹持结构的设计方法。依据直线超声电机夹持结构的设计准则建立了在弹性夹持下的定子力学模型；研究了夹持结构的法向和切向弹赞刚度对定、动子在接触界面上的法向压力和切向摩擦力的影响规律，并通过有限元软件进行了仿真分析。最后，提出了一种切向刚度充分大的夹持方式，并设计了相应的梁式夹持V型直线超声电机。通过实验对比了设计的梁式夹持超声电机与柔性圆式夹持电机的输出特性。结果表明：相对原有的圆弧式夹持电机，新直线超声电机的输出力增大了1.7倍，速度增大了4.6倍，其最大输出力达到37N，最大速度达到1.4m/s。研究表明，提高切向弹簧刚度有利于提高电机的输出力和速度，设计的梁式夹持V型直线超声电机输出特性及稳定性良好。
关键词：直线超声电机，卖持方法，力学模型，结构设计
中图分类号：TM359.4;TB559
文献标识码：A
doi:10.3788/OPE.20152305.1358
Structure design of beam type clamp for V-shape ultrasonic motor
JIAN Yue,YAO Zhi-yuan',YANG Mo-jian,LIU Zhen
(State Key Laboratory of Mechanics and Control of Mechanical Structures, NanjingUniversityofAeronauticsandAstronautics,Nanjing210016China)
Correspondingauthor,E-mail:zyyao@nuaa.edu.cn
Abstract: This paper focuses on the structure design of liner ultrasonic motors. The mechanical model of stators with flexible clamping components was established according to the design criterion for clamps of liner ultrasonic motors. Then the influence rules of tangential and normal rigidities of the clamping components on the normal pressures and tangential friction forces of stators and actors on a contact interface were researched and analyzed by finite element software. Finally, a new type clamping method with enough tangential rigidity was put forward, and the corresponding V-shape ultrasonic motor with beam type clamp components was designed. The output performance of the designed V-shape ultrasonic motor was compared with the original V-shape liner ultrasonic motor with flexible cambered clamp components. And the results show that the maximum output force of the designed motor reaches 37 N, 1. 7 times as high as that of the original motor, and the maximum no load speed is 1. 4 m/s, 4. 6 times as fast as that of original one. The concludes indicate that enhancing tangential rigidity is conducive to increasing the output force and velocity of the motor. The V-shape liner ultrasonic motor with beam type clamp components has great output performance and stability. Key words: linear ultrasonic motor; clamping method; mechanical model; structure design
收稿日期：2014-10-15；修订日期：2014-11-17
基金项目：国家973重点基础研究发展计划资助项目（No.2011CB707602）；国家自然科学基金资助项目（No.
51275229)；国家重大科学仪器设备开发专项资助项目（No.2012YQ100225）
