第39参第6期 2017年11月
石油钻采工艺
OIL DRILLING & PRODUCTION TECHNOLOGY
文章编号：10007393(2017)06076605
DOI:10.13639/j.odpt.2017.06.019
页岩含气量自动测定技术何家欢1.2.3李农1.2王兰生「张鉴1.2杜坚3靳涛了
1.中国石油西南气田分公司；2.四川省页岩气评价与开采重点实验宝；3.西南石油大学
Vol. 39 No. 6 Nov. 2017
引用格式：何家欢，李农，主兰生，张鉴，杜整，新涛.页岩含气量自动测定技术[J］.石油钻采工艺，2017,39(6)：766-770 摘要：由于应用于现场含气量测定的手动排水采气法难以满足页岩储层取样密度增加的需要，为此，研发出页岩含气量自
动测定技术。根据在U形管内的液体在同等大气压条件下其液体等高的等压液位平衡原理，采用光电非接融触式闭环测控方法，实现对页岩储层含气量的恒压等客自动连续测定。
现场应用表明，相邻并深的样品分别采用自动、人工计量方法的测量结采仅
相差0.03m/t，页岩含气量现场自动测定技术能够代替手动排水采气法，可满足页岩含气量现场测定的需要。该技术能有效减轻现场测试人页的劳动强度，且具有较高的精度，实现了页券含气量的自动、精准评价。该技术已成功应用于四川金地20余口页券气井的含气量现场测定，为四川盒地页岩气示范区（长宁、威选)的建设提供了强有力的数据支撑。此外，该项自动测定技术还能应用于煤层含气量的测定以及气体的连续计量测试。
关键词：页岩；含气量；自动测定；现场测定；四川盆地
中图分类号：TE122；P631.84
文献标识码：B
Automaticshalegascontentmeasurementtechnology 1. PefroChina Sourthwest Oil & Gas Field Company, Chengdu 610213, Sichuan, China;
2. Sichuan Key Laboratory of Shale Gas Evalaration and Exploitation, Chengdhr 610041, Sichun, China;
3. Southwest Petrolerm University, Chengdr 610500, Sichuan, Ching
Citation: HE Jiahuan, LI Nong, WANG Lansheng, ZHANG Jian, DU Jian, JIN Tao. Automatic shale gas content measurement technology [ J ] - Oil Drilling & Production Technology, 2017, 39(6): 766-770.
Abstract: The manual drainage gas recovery method that is applied to measure the gas content on site can hardly meet the measure-ment requirements when the sampling density of shale reservoir is increased. In this paper, an automatic shale gas content measurement technology was developed. According to the constant-pressure level equilibrium principle of the liquid of the same height in U-tube under the equal atmospheric pressure, photoelectric non-contacting closed loop measurement and control method is adopted to measure the gas content of shale reservoir automatically and continuously at constant pressure and volume. Field application shows that the difference between the manual measurement and the automatic one of the samples from the adjacent well depth is only 0.03 m'/t. It is indicated that on-site automatic shale gas content measurement technology can take the place of manual drainage gas recovery method and can meet the requirements of on-site shale gas content measurement. By virtue of this technology, the labor intensity of field tes-ters is reduced effectively. This technology is of higher precision and can evaluate shale gas content automatically and precisely. This technology has been successfully applied on site to measure the gas content of over 20 shale gas wells in the Sichuan Basin. It provides the vigorous data support for the construction of shale gas demonstration regions (Changning and Weiyuan) in the Sichuan Basin. This
基金项目：国家973计划项日“中国南方海相页岩气高效开发的基础研究"（编号：2013CB228006)：国家白点科学基金青年科学基金
项目“长宁-威远地区弹竹守组和五峰组-龙马演组要案储层特征对比及舍气性控制因素研究"（端号：41502150)。
第一作者：何家欢（1984-),2010年毕业于西南石油大学油气田开发工程专业，现主要从事油气田开发工程、油气渗流理论和实验研究
工作。通试地址：(610213)四川有成都市天府新区毕阳镇道天研路218号。电话：028-85604383。E-mail:HeJiahuan(@ petrochina.com.cn
