第38参第6期 2016年11月
石油钻采工艺
OIL DRILLING & PRODUCTION TECHNOLOGY
文章编号：10007393(2016)060859-04
DOI: 10.13639/j.odpt.2016.06.028
远程控制自动投棒系统的研制及应用
王小东段宝玉吴郁雷锐平？马纪翔熊巍周贤
1.中国石油华北田公司采沟工程研究院；2.陕西天成石油科技技术有限责任公司
Vol. 38 No. 6 Nov.2016
引用格式：王小东，段宝玉，吴郁，雷锐平，马纪期，熊毫，周赞.远程控制自动投棒系统的研制及应用[J］.石油钻采工艺， 2016,38(6):859-862.
摘要：天然气开采过程中常会出现并简积液现象，排水采气作业贯穿整个采气过程，导致日常维护管理工作繁重。针对目前自动投棒装置内部带压、操作存在安全隐惠等问题，设计了一套送程控制泡排棒自动投放系统，主要包括井口授棒装置、本地控制系统选程控制系统。整个系统的并口投棒装置上设计有压力平衡装置和投举监测装置，从而实现了投棒腔体与并口压力
机系统在现场进行试验，实现了定时定量自动投棒，系统稳定可靠。该系统的成功研制大大降低了工人劳动强度，提高了泡排效率，具有一定的雅广应用价值。
关键词：泡排棒；平衡阀；红外传感器；自动投棒；远程控制；上位机
中图分类号：TE931
文献标识码：B
Development and application of remote-controlling automatic bar dropper system
WANGXiaodong,DUAN Baoyu',WUYu',LEI Ruiping,MA Jixiang,XIONG Wei',ZHOU Xian
1.Producrion Engineering Research Irstitute of PetroChina Huabei Oilfeld Company, Renqir 062552, Hebei, China 2. Shaanri Tiancheng Perolerm Science and Technology Developmenr Co. Lid., Xr'an 710018, Shaanxi, China
Citation: WANG Xiaodong, DUAN Baoyu, WU Yu, LEI Ruiping, MA Jixiang, XIONG Wei, ZHOU Xian. Development and ap-plication of remote-controlling automatic bar dropper system [J J . Oil Drilling & Production Technology, 2016, 38(6): 859-862.
Abstract: Downhole fluid accumulation is a common phenomenon in the process of natural gas production, therefore water drain-age operation is required constantly, leading to heavy workload related to routine maintenance. Conventional automatic bar dropper sys-tems are characterized by deployment of intemal pressure and high risks in operation safety. To eliminate such problems, an innovative remote controlling automatic dropping system with foam-drainage bars has been developed. Major components of the system include wellhead bar dropper, local control system and remote control system. With pressure balancing devices and bar dropper monitoring de-vices deployed, the newly development system can effectively balance the pressure in the bar-dropping chamber and the wellhead pres-sure to protect the foam-drainage bar against damage caused by strong gas fiow around the wellhead. In addition, these devices may be used to monitor and record bar dropping processes. Host computer systems for the innovative remote controlling system have been tested in field to control the automatic bar dropper system safely and reliably. The newly developed system can effectively reduce manpower, enhance foam drainage efficiency and can be applied more extensively
Key words: foam-drainage bar; balance valve; infrared sensor; automatic bar dropper system ; remote control; hose computer
在天然气井开采的中后期，气井压力逐渐下降、产水量逐年增加，导致气井严重积液甚至停产。为了排除井内积液，现场工程技术人员和专业科研人
员研究出了多种排水采气工艺方法。经过大量的现场试验应用，目前现场常用的主要有气举法、柱塞法、泡排法1-2。上述3种排水采气工艺中，泡沫排
第一作者：王小东（1983-),2013年毕业于西安石油大学石油与天然气工程专业，硕士研究生，现从事采气工程研究工作，工程师。通试
地址：(062552)河北省任丘市华北沟田公司来油工程研究统。电语；0317-2720414。E-mail:cyy_wangxd@petrochina.com.cn
