第20卷第7期 2012年7月
文章编号
1004-924X(2012)07-1485-07
光学精密工程
Optics and Precision Engineering
飞机数字化测量网络布站设计
周娜1，安志勇1，李丽娟1，朱运2
（1.长春理工大学光电工程学院，吉林长春130000；
2.中国航空工业集团长春航空液压控制有限公司，吉林长春130000）
Vol. 20No., 7
Jul.2012
摘要：考虑大尺寸、高精度要求的飞机或特殊机型飞行器需要采用多仪器组合测量网络来完成数字化测量任务，本文对测量网络进行了最优布站设计。介绍了传统的飞机调平理论，提出了飞机数字化调平变换算法，并建立了其不确定度模型。通过不确定度分析和误差依赖性仿真得出飞机各基准点不确定度和水平点位置对测量不确定度的影响。结合由激光雷达、iGPS组成的飞机数字化测量网络的测量特性，提出了飞机数字化测量网络的最优布站设计方案。对某机型飞机水平测量实验验证表明，经布站优化设计后的测量结果精度为0.402mm，提高了约20%。结果显示提出的布站设计
方案有效、可行，其分析方法为寻找高准确度、高效率的飞机数字化测量的布站设计提供了参考依据。关键调：飞机数字化测量；测量网络；最优市站；激光雷达；iGPS；不确定度模型；
中图分类号：V262.4
文献标识码：A
doi:10.3788/OPE.20122007.1485
Designofmulti-stationnetworkarrangementfor
aircraftdigitalmeasurement
ZHOU Na'',AN Zhi-yong',LI Li-juan',ZHU Yun
(l1.Instituteof Photoelectric Measurement and Control Technology,Changchun University of Science and Technology,Changchun 130000,China; 2.Changchun Company of Hydraulic Test,
AviationIndustryCorporationofChina，Changchun130052,China)
+Correspondingauthor，E-mail;anjojo@126.com
Abstract: As some aircrafts with large sizes, high accuracy or special structures need multi-instrument combination measurement networks to complete its digital measurement, this paper researched the op-timal arrangement design of measurement networks. The traditional aircraft leveling theory was intro-duced firstly. A aircraft digital leveling algorithm was put forward, and its uncertainty model was es-tablished. Then, the effect of the accuracy of level benchmark points and the location of level points on the measuring accuracy was studied through the uncertainty analysis and error dependence simula tion. Based on the measurement characteristics of the aircraft digital measurement network consisted of a laser radar and an iGPS, the optimal multi-station arrangement design of aircraft digital measure-ment network was put forward. Experimental results of aircraft leveling measurement show that the measurement accuracy of optimal multi-station arrangement design is 0. 402 mm, which has improved by 2o%. The optimal arrangement design is feasibility and effectiveness, and propsed analysis method
收稿日期：2012-02-16；修订日期：2012-05-17.
基金项目：吉林省科技厅重大项目（No.20106010）
