第5期 2017年5月
组合机床与自动化加工技术
Modular Machine Tool & Automatic Manufacturing Technique
文章编号：10012265(2017)05011804
DOI:10. 13462/j. cenki. mmtamt. 2017. 05. 031
基于三维模型的装配工艺优化与
计算机集成系统研究
陶小刚"，郝博2
No.5 May2017
（1.沈阳理工大学机械工程学院，沈阳
日110159；2.辽宁机电职业技术学院，辽宁丹东
118009）
摘要：针对齿轮泵装配工艺规划中三维建模与装配工艺信息素脱节，且二维计算机辅助装配工艺过程设计不能动态反映零部件装配工艺过程与干涉性等问题，提出了一种基于3DCAPP-A的装配工艺优化方法。通过对齿轮泵三维建模分析和装配信息素提取，完成3DCAPP-A与UG集成系统创建；其次在3DCAPP-A环境中对齿轮泵装配信息素进行完善添加，建立三维装配工艺知识库，为装配工艺专家系统设计提供知识来源；最后利用UG二次开发工具，对装配工艺专家系统进行开发技术研究，结合实例表明，运用专家系统和UG集成开发技术，可以实现装配工艺信息素的流动，并能动态反映零部件装配工艺过程与干涉性等问题；减少二维视角带给技术人员的模糊装配设计，从而降低生产成本，提高效率。
关键词：齿轮泵；三维建模；装配工艺；UG二次开发；专家系统
中图分类号：TH166;TG506
文献标识码：A
Research on Assembly Process Optimization and Computer Integrated System Based on 3D Model
TAO Xiao-gang',HAO Bo2
( 1. School of Mechanical Engineering , Shenyang Ligong University , Shenyang 110159 , China ;2. Liaoning Jidian Polytechnic, Dandong Liaoning 118009, China)
Abstract: This Thesis has put forward an assembly process optimization method which is based on 3DCAPP-A for problems that the 3D modeling in gear pump assembly process planning is divorced from as-sembly process information elements and the 2DCAPP fails to dynamically reflect the assembly process of sneeaaeeaaeseeao sembly information elements, the thesis has firstly completed the establishment of 3DCAPP-A and UG inte-grated system; secondly, it has improved and added assembly information elements for gear pump in 3DCAPP-A environment and built a knowledge base of 3D assembly process which can provide knowledge source for assembly process expert system planning; and lastly, it has carried out technological development research on assembly process expert system by making use of UG secondary development tools. Combined with examples, it shows that by applying expert system and UG integrated development technology, the mobility of assembly process information elements can be realized and the assembly process of components and parts and its interference can also be reflected dynamically; meanwhile, it can reduce fuzzy assembly design that two-dimension view brings to technicians so as to lower production costs and improve production efficiency.
Key words: gear pump ;3D modeling ; assembly process; UG secondary development;expert system
0
引言
在产品的整个生产阶段，装配工作成本约占总制
造成本的40%~60%左右，装配活动在产品整个生产过程中任务最繁重，要求也最高，在很大程度上影响了制造过程的效率、质量和成本，所以合理优化装配工
艺过程可以减少产品研发与制造的周期[]。建立合理的装配工艺信息模型不仅是对装配过程出现的问题和解决措施的模拟，实现计算机辅助工艺设计系统的基础，同时对于各软件间的计算机集成制造系统（CIMS）的信息集成以及信息传递也至关重要
随着机械行业信息化、网络化程度的不断提高，计
收稿日期：20170103；修回日期：20170118
*基金项目：国家自然基金资助项目(61170146）：国家自然科学基金（61672360）
作者筒介：陶小别（1993—），男，安微芜潮人，沈阳理工大学土研究生，研究方向为数字化网络化设计与制造技术，（E-mail)tglove248@163.
com
